3067-FA – Reel Turning Axle Assembly

The 3067-FA Reel Turning Axle Assembly is a heavy-duty axle component designed to support controlled rotation of reel turning systems on trailers. This final assembly includes the required spline coupler and mounting hardware to ensure secure engagement and reliable torque transfer during reel rotation.

Commonly used on Larson Cable Trailers, this assembly is ideal for replacement, service, or new builds requiring dependable reel turning performance.

Kit Includes

• (1) 3148 – Spline Coupler
• (4) 37C125BCG0Z – 3/8-16 x 1-1/4″ Carriage Bolts
• (4) 37CNNE0Z – 3/8-16 Nylon Insert Lock Nuts

Specifications

• Part Number: 3067-FA
• Component Type: Reel turning axle (final assembly)
• Axle Function: Reel rotation / torque transfer
• Hardware Size: 3/8″-16
• Fastener Length: 1-1/4″
• Construction: Steel
• Application: Reel turning and handling systems

Fitment

• Designed for use on select Larson Cable reel turning rack systems
• Interfaces with turning rack tires, hubs, and reel racks
• Verify spline compatibility, mounting brackets, and hardware clearance before installation
